First Product

|HVAC duct fabrication machineⅢ

HVAC duct fabrication machineⅢ

HVAC duct fabrication machine Ⅲ features in high auomation,high efficiency and saving materials,which is very suitable for mass production of square ducts. Autoline - III consists of a metal feeding frame, leveling and grooving equipment, hydraulic punching square notch equipment, hydraulic cutter and folder. The electrical control system uses a computer with a closed-loop and servo-system to increase the precision and reliability of the manufacture line. The maximum working speed is 16m/min.The length tolerance is±0.3mm. The diagonal line tolerance is ±0.5mm.   One team will produce 1000㎡of square duct by using this system.
  • Product Details

Characters of HVAC Duct Manufacturing Line:

Duct Manufacturing Machine Line III is controlled by computer and this control system is equipped with closed-loop feedback system,so it helps improve manufacturing precision and stability.

HVAC duct machine Working Schematic Diagram:

Working Principle:Ventilation Duct Machine Basic Equipment:

One electric coiler frame

Leveler and grooving device

Four hydraulic notching and punching device

Hydraulic shearer and folding machine

Industrial computer and production software
