Fire Damper Manufacture Auto Line

|Spring forming machine for fire damper machine

Spring forming machine for fire damper machine

The spring forming machine for fire damper machine adopts PLC control, LCD touch screen, human-computer interface. Realize the interaction between human and Panasonic PLC. The operator can automatically run (programmable control) and monitor the control process through the set program, so as to realize the operator to control the production line and modify the control parameters, and monitor the equipment operation status, operation parameters and fault indication in real time. The length of the work piece can be adjusted.
  • Product Details

Electrical control system of spring forming machine:
PLC: Panasonic of fpx-c30t
True color touch screen: Taiwan Winon
Detection encoder: Japan internal secret control encoder
Servo drive system: Viktor (or invetion) servo drive system
Low voltage electrical appliances: circuit breakers and contactors are domestic famous brand "Chint" electrical appliances, and relays are "Omron" or "Schneider".

Finished products:

Product drawing:

Description of function:

●Servo driving,full automation operation

●Automatic punching,fixed length cutting

Free setting punching number and punching space

●Order mode

Basic Configuration:

1.One powerless decoiler

2.One set of supporting bar forming machine

3.One suit of hydraulic shearer

4.One set of automatic punching

5.One set of collecting platform

6.One suit of digital controlling system

7.One suit of hydraulic system
