Je23 Series Punching Machine

Contact Now Whatsapp

Product Categories

Hot products

Product Details

Product features: copper crankshaft structure, rigid key clutch,two hands protection starting device, automatic oiler, automatic cylindercontrol switch.Different molds choose diferent punch presses,semi-automatic molds. full automaticmolds (including feeding rack, leveling machine, servo feeding)

40 Ton TDF automatic corner punching machine video：

63 TON TDC automatic corner punching machine video：

名称 Description 技术参数 Specification 型号 Type		JG23-40D	JC23-63D	J23-80D
公称力 Nominal force	kN	400	630	800
滑块行程 Slide stroke	mm	20-120	20-120	10-130
行程次数 SPM	min⁻¹	55	55	50
最大装模高度 Max die height	mm	210	220	270
装模高度调节量 Die height adjustment	mm	70	80	80
工作台板尺寸（前后×左右） Bolster(F·B×L·R)	mm	400×660	450×700	480×780
工作台板落料孔尺寸（上孔直径×深度×下孔直径） Bolster opening(up dia × depth × low dia)	mm	Φ220×25×Φ180	Φ200×45×Φ180	Φ200×45×Φ180
工作台板厚度 Bolster thickness	mm	80	90	100
机身工作台孔尺寸（直径×前后×左右） Bed opening(Dia×F·B×L·R)	mm	Φ200×150×300	Φ250×200×340	Φ250×200×340
模柄孔尺寸（直径×深度） Shank hole (Dia×Depth)	mm	Φ50×70	Φ50×80	Φ60×75
立柱间的距离 Bettween columns	mm	250	280	320
主电机功率 Main motor power	kW	3	4	5.5
外形尺寸（前后×左右×高） Outline dimension(F·B×L·R×H)	mm	1200×1100×2300	1500×1300×2500	1800×1600×2650
重量 Weight(KG)		2500	3200	4200

Hot Tags: Punching Machine Punching Je23 Series

Get A Free Quote

If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.

Subject : Je23 Series Punching Machine

If you have questions or suggestions,please leave us a message,we will reply you as soon as we can!

Duct Manufacturing Auto Line Vl

HVAC duct line VI,the U-shaped structure not only saves the production site, but also reduces the delivery time of raw materials. The production efficiency is high (about 20-23 seconds per piece). The department fully automatically realizes the fixed size cutting, beading, automatic cutting ,the notching,pittsburgh forming, TDF flange and the angle iron flange ,automatically forming and bent into ”L“, ”U“, ”口“ shaped duct. Equipped with punching support air, common plate flange hole is optional.It has the advantages of high automation, high efficiency, labor saving and material saving.

Duct Manufacturing Duct Line V

Ventilation duct machine The air duct production line V is composed of feeding frame, leveling and beading, hydraulic punching point and square mouth, hydraulic shearer, movable pittsburgh forming machine,feeding platform, duplex flange machine, duplex angle iron flange machine (or double snap lock machine), servo feeding platform and TDF hydraulic folding. The computer control part adopts full computer control, bending with servo feeding, accurate positioning, especially when processing the bigger air duct, to ensure the bending accuracy.

Duct Manufacturing Auto Line II

Air Duct Machine Line Ⅱ is mainly for TDF flange blanking,meanwhile,it can be used for normal sheet blanking.Matched with TDF forming machine,pittsburgh lock former,folder and angle joint joint,the line can produce nice TDF ducts.

TDF Flange Forming Machine

TDF flange forming machine applies both sides feeding and simultaneously shaping work mode, one side forming and one side forming is for installing hooks. TDF folder is with hydraulic,pneumatic,manual type.

TDC Flange Forming Machine

TDC Flange Forming machine is the advanced technique in the world to manufacture square duct.It realizes standard,automation and mass production during producing rectangle flanges.

Pittburgh lock forming machine

Duct lock forming machines can process galvanized sheet with different thickness into various shapes,such as profile pittsburgh,single hem,double hem,snap hem,elbow,S shape and so on.

TDF Flange Folding Machine

HVAC square metal folding machine comes into being serialization,including hydraulic,pneumatic,manual，which offers customers many choices.

Quintuple Groove Beading Machine

HVAC Quintuple Groove Beading Machine press the sheet with no limited length and form several reinforced veins.The veins are to stiffen the plate.Clients can order the machine according to thickness,width and number of beads on metal sheet.

Lock Seam Closer

Whisper-Lock Seam Closer is available in the horizontal or vertical and close pittsburgh seams.Pittsburgh joint is commonly used by manually hammering the margin of the seam against the duct wall(peening).It is suitable for plates of different thickness.To some extend,it can produce any size duct.
